Welcome to the course "Digital Multimeter as a Measurement Device."
In today’s world of electronics and electrical systems, the Digital Multimeter (DMM) is an essential tool used to measure voltage, current, resistance, and other parameters. It is widely used in industries such as electronics, automotive, HVAC, and electrical maintenance.
This course aims to provide you with fundamental knowledge and hands-on skills to use a digital multimeter safely, accurately, and effectively. You will learn how to operate the device, understand its functions, and apply it in real-world scenarios.
Topics covered include:
Introduction to DMM and its components
Proper use of test and safety procedures
Common applications, troubleshooting and practical exercises
By the end of this course, you will be able to:
Identify key features of a DMM
Perform accurate measurements using the correct settings
Follow safety standards when working with electrical circuits
Apply DMM skills to diagnose and solve basic electrical issues
This course is suitable for students, technicians, and anyone interested in developing basic electrical measurement skills.
Let’s begin the journey to mastering one of the most important tools in the electrical field — the Digital Multimeter.
A Digital Multimeter (DMM) is an electronic measuring instrument used to measure electrical values such as voltage (V), current (A), and resistance (Ω).
It combines the functions of a voltmeter, ammeter, and ohmmeter into a single device, with a digital display that shows the measured values in numbers for easy reading.
DMMs are widely used in electronics, electrical work, and troubleshooting because they are:
Accurate
Portable
Easy to use
Most modern DMMs also include additional features such as continuity testing, diode testing, frequency, and capacitance measurement.
Display Screen
Dial/Rotary Switch
Function Buttons
Input Terminals (Probes Ports)
Test Probes
Battery Compartment
Fuse
Turn on the multimeter.
Set the dial to the correct voltage type:
DCV to measure batteries, DC circuits
ACV to measure wall outlet voltage
Connect the probes:
Red probe to VΩmA port
Black probe to COM port
Touch the probes across the two points you want to measure.
Red probe to the positive side
Black probe to the negative/ground side
Read the value on the display.
Turn on the multimeter.
Set the dial to the correct current type:
DCA to measure current in DC circuits (e.g., batteries, electronics).
ACA to measure current in AC circuits (e.g., household appliances).
Connect the probes:
Red probe to the 10A or mA/μA port (depending on the expected current range).
Black probe to the COM port.
Break the circuit and place the multimeter in series with the load:
Current must flow through the meter, unlike voltage measurement.
Connect the red probe to the side closest to the power source.
Connect the black probe to the load side (return path).
Read the value on the display.
Turn off the power to the circuit or component.
Never measure resistance on a live circuit.
Turn on the multimeter.
Set the dial to the resistance (Ω) mode.
Some meters have ranges; choose the appropriate one.
Many digital meters auto-range automatically.
Connect the probes:
Red probe to the VΩmA port.
Black probe to the COM port.
Place the probes across the component or points where resistance is to be measured:
Polarity does not matter.
Ensure no parallel paths affect the reading.
Read the resistance value on the display (in ohms, Ω).
A Digital Multimeter (DMM) is a versatile tool widely used in electronics, electrical work, and troubleshooting. Its main applications include:
Measuring Voltage (AC/DC)
Used to check battery voltage in electronics and vehicles.
Test wall socket voltage to ensure proper supply.
Verify power supply output in electronic devices.
Measuring Current (AC/DC)
Determine how much current flows through a circuit.
Check for excessive current draw in appliances or automotive circuits.
Monitor battery discharge or charging current.
Measuring Resistance (Ω)
Test resistors to verify their values.
Check for continuity in wires, fuses, or circuit connections.
Identify open or short circuits.
Continuity Testing
Quickly test if a wire or connection is intact.
Emits a beep sound when the path is complete.
Useful for checking cables, PCB tracks, and switches.
Diode Testing
Measures the forward voltage drop of a diode.
Ensures the diode allows current in only one direction.
Helps identify faulty diodes in power supplies and rectifiers.
Capacitance Measurement (on advanced DMMs)
Used to measure capacitor values.
Helpful in troubleshooting power circuits and electronic boards.
Frequency Measurement (on advanced DMMs)
Measures frequency of AC signals.
Useful in testing oscillators, inverters, and power systems.
Temperature Measurement (with probe)
Some DMMs allow temperature readings using a thermocouple probe.
Applied in HVAC, refrigeration, and electronics testing.
A Digital Multimeter helps identify faults in electrical and electronic circuits. Some common troubleshooting techniques are:
Check Power Supply (Voltage Test)
Measure voltage at the power source (battery, adapter, outlet).
If there is no voltage, the problem is with the power supply.
Check Continuity (Broken Wires / Connections)
Use continuity mode (beep test) to check if a wire, switch, or fuse is intact.
If there’s no beep, the wire or component is open/broken.
Check Resistance (Component Testing)
Measure resistor values to ensure they match their rating.
High or infinite resistance may indicate a damaged component.
Check Current Flow
Place the DMM in series with the circuit.
If no current flows, a component may be faulty or the path is open.
Check Diodes and Transistors
Use diode mode to test if a diode conducts in one direction only.
For transistors, check junctions for correct forward/reverse bias readings.
Isolate the Fault
Test one section of the circuit at a time (input, mid, output).
Compare readings with expected values to locate the faulty part.
